Precision Heat Shrink Tooling for CNC Machines

Shrink Fit Tool Holders are precision-engineered tool holding systems designed for maximum accuracy and rigidity in high-speed CNC machining. Unlike conventional tool holders, Heat Shrink Tool Holders utilize thermal expansion and contraction principles to secure the cutting tool, providing superior concentricity and eliminating runout.

Our product range includes CAT 40 Shrink Fit tool holders, BT40 Shrink Fit Holders, BT30 shrink fit holders, and universal shrink fit tooling solutions compatible with a wide variety of milling machines and machining centers. For precise installation and removal, we also offer shrink fit tool holder machines or heat shrink machines for tool holders, ensuring consistent and safe performance.

Core Advantages

Key Features

1. Thermal Clamping Technology: The shrink fit holders use controlled heating and cooling to tightly grip the tool shank, eliminating the need for drawbars.

2. Wide Size Range: Supports BT30 shrink fit holders, BT40 shrink fit holders, CAT 40 shrink fit tool holders, and custom tooling diameters.

3. High-Speed CNC Machining: Ideal for high-speed milling, drilling, and engraving with minimal vibration.

4. Heat Shrink Machines Available: Compatible with heat shrink tool holder machines for fast, safe, and precise tool installation.

5. OEM & Customization: Custom taper lengths, shank diameters, and coatings available for specialized machining requirements.

Applications

• High-speed CNC milling centers

• Precision mold and die manufacturing

• Aerospace and automotive component machining

• General metalworking and industrial equipment

• Engraving and fine detail machining

Whether you are using a BT30 shrink fit for small-diameter end mills or a CAT 40 shrink fit tool holder for heavy-duty milling, our shrink fit tooling ensures maximum stability and accuracy.

Technical Parameters

Why Choose Shrink Fit Tool Holders

• Superior concentricity and clamping precision compared to conventional collet or mechanical holders

• High-speed machining capability with reduced vibration and chatter

• Compatible with all standard milling machines and CNC spindles

• Reduced spindle wear and extended cutting tool life

• Quick tool changes using heat shrink tool holder machines or heat shrink machine for tool holders

Comparison with Conventional Tool Holders

FAQ

Q1: What is a shrink fit tool holder?
A: A shrink fit tool holder uses thermal expansion to grip the tool shank securely. It provides high precision and eliminates runout during high-speed CNC machining.

Q2: How do I install a shrink fit tool?
A: Using a heat shrink tool holder machine or heat shrink machine for tool holders, the holder is heated to expand, the tool is inserted, and as it cools, it tightly grips the tool.

Q3: What sizes are available?
A: We offer BT30 shrink fit holders, BT40 shrink fit holders, CAT 40 shrink fit tool holders, and customized tooling diameters.

Q4: Can shrink fit holders be used on milling machines?
A: Yes, our shrink fit holders are ideal for collet holder for milling machine and CNC machining centers.

Q5: Are there custom options?
A: Yes, we provide shrink fit tooling customization including taper type, shank diameter, and coatings for specific applications.
